Product Overview
Aqualine Model 2702LP
Proudly manufactured in Texas from American steel and comes with the highest quality potable water liner manufactured by Bartlett.
20 Year Manufacturer Warranty
Dimensions
27' Diameter x 7' 4" Eave Height x 9' 9" Peak Height
Documentation
37,078 Gallon - Aqualine Water Storage Tank - Model 2702LP
STANDARD TANK ACCESSORIES
• 2” Outlet and Ball Valve
• 6” Overflow Assembly with Down Pipe & Flapper
• 24” Access Hatch
• Leaf Filter Basket for Rainwater Collection (May be substituted with a top/sidewall bulkhead fitting for filling with well water)
• Liner Underlayment
Call 877-331-7008 or email ar@rainwaterequipment.com for pricing.*
*Note: When emailing your request, please include the location of the project, and let us know what the water will be used for.
Short Lead Times: Typically 3-4 weeks
10 Degree Pitched ROOF
OPTIONAL ACCESSORIES
• Galvanized Steel Flanges 2” - 12”
• 2” Stainless Bulkhead Fittings
• Bolted Access Wall Panels
• Ladder, Ladder Block Off, Ladder Safety Cage
• Anti-Vortex Assembly
• Mechanical Level Indicators
• Rural FDC Connections
• FDC Connections
• OS&Y Gate Valve
TANK COMPONENTS
• Bolts & Nuts: Grade 5
• Trusses: Galvanized
• Roof Screws: Hex head with sealing washer ASTM A 510
• Wall Panels: .040 (20 gauge) corrugated G90 galvanized
• Dome Roof Panels: 26 gauge corrugated Galvalume
• 30 degree Roof Panels: G90 Galvanized
• Bartlett Potable Water Liner: BPA-Free and Phthalate-Free
• Plumbing Outlets: Poly nylon OR stainless
• Ball Valves: Stainless
• Flanges - Hot Dipped Galvanized
FOUNDATION/PAD
These Aqualine Tanks may either be constructed on a compacted base pad or concrete pad. Contact Rainwater Equipment for specifications. Pads are typically Not included.
TOP OF THE LINER
Aqualine goes to great lengths to provide clients with the finest, most robust and longest lasting water tanks available. But let’s face it, a water tank is only as good as the liner that goes inside it. That’s why Aqualine exclusively partners with Bartlett Tank Liners.
Bartlett is the industry leader and makes the most durable liners in the world and they manufacture custom fitted liners for every Aqualine Water Tank.
SAFETY
The Bartliner® DST is a woven polyethylene, Food grade liner manufactured in Bartlett Tank Liners’ NSF-61 accredited facility. The liner is also certified for products for use in contact with drinking water.
STRENGTH
The Bartliner® DST provides strength and integrity via its multifilament weave, unlike unsupported liners that are likely to shrink, stretch and tear in water tank applications.
FLEXIBILTY
Flex tested to 400,000 cycles, The Bartliner® DST withstands even the most regular fill cycles of your domestic tank.
INTEGRITY
The Bartliner® DST comes with an exclusive Double Seal Tape Welded Seam. The seal tape provides added integrity to the welded seams as well as providing an additional barrier to protect against tree root and pest intrusion.
PEACE OF MIND
You can trust Bartliner® DST liners are among the longest lasting, highest quality liners in the world!
