ATER 20-SERIES - Bottom-Suction 120V Effluent Pump

$299.95
SKU:
ATR-EFP-BS0512018
Weight:
10.00 LBS
Shipping:
Calculated at Checkout
Adding to cart… The item has been added

Product Overview

NOTE: Shipping Rate not available in Hawaii, Alaska or Puerto Rico.

The bottom suction design allows for the unit to pump longer giving you further draw-down capability and more reliably without losing prime.

20-Series Septic Effluent Pump

Ater Pump 20-Series was specifically designed to be used in septic effluent and cistern pumping where maximum draw down is needed. The 20Series was built using 304 stainless steel and high-wear life thermoplastic ensuring corrosion resistance and longevity. Ater 20Series also has 5 stages for maximum shut-off head pressure of 170ft of head.

Internal diffuser design provides high performance and long life in harsh water conditions. The pump can pass solids up to 1/8 inch with no negative effect on the internal components. The unique hollow-wall design eliminates the need for an induction sleeve as the pump-end is on the bottom and the water passes past the motor on its way to the diffusers, cooling it continuously.

This makes the 20Series the most sought-after unit and highly versatile in application uses:

  • Filtered effluent from aerobic septic systems
  • Grey water pumping applications
  • Filtered effluent service water pumping
  • Water reclamation such as rain harvest basin pumping
  • Agriculture and livestock water pumping

‍Key Features

  • Gallons Per Minute: 20 GPM
  • CSA Approved: Certified by the Canadian Standards Association for Safety and performance standards.
  • Solid Handling Capability: Can pass solids up to 1/8-inch without issues.
  • Built-in Check Valve: Prevents Backflow.
  • High-Quality Materials: Internal components are molded from durable thermoplastics.
  • Corrosion Resistance: Made of high-grade 304 stainless steel.
  • 5 Diffusers: Enhance pump longevity.
  • Voltage Options: Available with 115 VAC. 1/2 h.p. motor.
  • Heavy Duty Cord: Equipped with a 10 ft SJOW jacketed cord.

Technical Specifications

  • Motor Power: 0.5 Horsepower (H.P.).
  • Discharge Bearing: Made of Nylatron.
  • Voltage: 115V/60Hz
  • Maximum Head Pressure: 125 Feet.
  • Maximum Flow Rate: 31 Gallons per Minute.
  • Shell Material: 304 Stainless Steel.
  • Suction Type: Bottom-Suction
  • Discharge Thread: FNPT (Female National Pipe Thread).
  • Discharge Diameter: 1.25 inches.
